If the measurement type is set to “Voltage”, the values are as
followed:
 The voltage increment between Cursor A and Cursor
B: ΔV
 The value of Cur A: CurA
 The value of Cur B: Cur B
If the measurement type is set to “Time”, the values are as
followed:
 The time increment between Cursor A and Cursor B:
ΔT
 The reciprocal of time increment between Cursor A
and Cursor B: 1/ΔT
 The value of Cur A: CurA
 The value of Cur B: Cur B
Figure 3.38 – Cursor Menu (Manual)
Track Mode
Table 3.36 – Track Mode Menu
Option
Setting
Description
Cursor Mode
Track
In this mode, set track cursor
measure.
