70
Set up Averages
When you select “Average” format, you can press the “Averages” option
button to select “4”, “16”, “32”, “64”, “128”or “256”.
Set up function interpolation
You can select Sinx interpolation or linear interpolation.
Set up Sampling Mode
Press the “Mode” option button to select “Real Time” or “Equ Time”.
Set up Sampling Rate
The sampling rate is based on the time division scaling on the screen.
Adjust the sampling rate by turning the Time/div front panel knob. The
sampling rate is shown under the “Sa Rate” display.
3.13 Display System
The display function can be setup by pressing the “DISPLAY” button.
Table 3.32 – Display System Menu 1
To Next Page
