4 Application Examples
This section presents a series of application examples. These simple
examples highlight the features of the oscilloscope and give ideas for using
it to solve your own test problems.
• Taking simple measurements
• Taking cursor measurements
• Capturing a single-shot signal
• Analyzing signal detail
• Triggering on a video signal
• Application of X-Y function
• Analyzing a differential communication signal using math functions
4.1 Taking Simple Measurements
Observe an unknown signal in a circuit, display the signal quickly and
measure the frequency and peak-to-peak amplitude.
• Using Auto set
To quickly display a signal, follow these steps:
1. Press the CH1 button, set the Probe option attenuation
to 10X and set the switch to 10X on the probe.
2. Connect the channel 1 probe to the signal.
3. Press the AUTO button.
4. The oscilloscope sets vertical, horizontal, and trigger
controls automatically. If you want to optimize the
display of the waveform, you can adjust these controls
manually.
To Next Page
