Normal: The waveform refreshes when the trigger
condition is satisfied and waits for next trigger event
occurring when the trigger condition is not satisfied.
Single: The oscilloscope acquires a waveform when the
trigger condition is satisfied and then stops
5. Set up Trigger coupling
 Press the “Set Up” button to enter the “Trigger Setup
Menu”.
 Press the “Coupling” option button to select “DC”, “AC”,
“HF Reject” or “LF Reject”.
Pulse Trigger
Use Pulse Width triggering to trigger on aberrant pulses.
Table 3.17 – Pulse Trigger Function Menu 1
Option
Setting
Description
Type
Pulse
Select the pulse to
trigger the pulse match
the trigger condition.
Source
CH1
CH2
EXT
EXT/5
AC Line
Select input signal
source.
