BK Precision 2190D User Manual

5
User Interface Description
Trigger Level Display Marker
Vertical Display Markers (Ground Reference)
Channel Source, Coupling Type, Volts/Division, BW Limit Indicator
Timebase Setting
Horizontal Trigger Position Display
Frequency Counter
Trigger Source, Type, and Level Indicator
Rear USB Indicator
Print Key Save Function Indicator
Waveform Display Preview
Horizontal Trigger Position Marker
USB Flash Drive Indicator
Trigger Status
13
1
2
3
4
5
6
7
8
9
10
11
12
