3
Probe Compensator (1 kHz and Ground)
Horizontal Controls (Time Base)
Trigger Controls
Auto Function Button
Menu and Measurement Buttons
Universal Knob
Vertical Controls
1.4 Back Panel
The following images show back and side panel connection locations.
Figure 1.2 – Back Panel
1
2
3
4
5
6
6
10
9
4
5
7
8
