76
parameters.
Source
CH1
CH2
MATH
REFA
REFB
Select input signal channel.
Cur A
Select this option, use “Universal”
knob to adjust cursor A.
Cur B
Select this option, use “Universal”
knob to adjust cursor B.
In this mode, the screen displays two horizontal parallel cursors or vertical
parallel cursors to measure voltage or time. You can move the cursor by
turning the “Universal” knob. Before using cursors, you should make sure
that you have set the signal source as the channel for measuring.
 Voltage Cursor: Voltage cursors appear as horizontal lines on the
display and measure the vertical parameters.
 Time Cursor: Time cursors appear as vertical lines on the display
and measure the horizontal parameters.
 Cursor Moving: Use the “universal” knob to move cursor 1 and
cursor 2. They could be moved when the corresponding cursor
option are selected, and cursor value will display on the bottom
left and top left of the screen when you move the cursor.
To do manual cursor measurements, follow these steps:
1. Press CURSOR button to enter the cursor function menu.
2. Press the “Cursor Mode” option button to select “Manual”.
3. Press the “Type” option button to select “Voltage” or “Time”.
4. Press the “Source” option button to select “CH1”, “CH2”,
“MATH”, “REFA”, “REFB” according to input signal channel.
5. Select “Cur A”, turn the “Universal” knob to adjust Cursor A.
6. Select “Cur B”, turn the “Universal” knob to adjust Cursor B.
7. The measurement values are displayed on the top of the left
corner.
