BK Precision 2190D User Manual

78
Cursor A
CH1
CH2
NONE
Set the input signal channel that
the Cursor A will measure.
Cursor B
CH1
CH2
NONE
Set the input signal channel that
the Cursor B will measure.
Cur A
Select this option, turn the
“Universal” knob to adjust
horizontal coordinate of Cursor A.
Cur B
Select this option, turn the
“Universal” knob to adjust
horizontal coordinate of Cursor B.
In this mode, the screen displays two cross cursors. The cross cursor sets
the position on the waveform automatically. You could adjust cursor’s
horizontal position on the waveform by turning the “Universal” knob. The
oscilloscope displays the values on the top left of the screen.
To do track cursor measurement, follow these steps:
1. Press CURSOR button to enter the cursor measure function
menu.
2. Press the “Cursor Mode” option button to select “Track”.
3. Press the “Cursor A” option button to select the input signal
channel.
4. Press the “Cursor B” option button to select the input signal
channel.
5. Select “Cur A”, turn the “Universal” knob to move Cursor A
horizontally.
6. Select “Cur B”, turn the “Universal” knob to move Cursor B
horizontally.
7. The measurement values are displayed on the top left of the
screen:
A→T: The horizontal position of Cursor A (Time cursor
centered around the midpoint of screen).
