18
(Falling edge)
Auto set and show the falling time.
(Undo Setup)
Causes the oscilloscope to recall the
previous setup.
Auto Set determines the trigger source based on the following conditions:
• If multiple channels have signals, channel with the lowest
frequency signal.
• No signals found, the lowest-numbered channel displayed when
Auto set was invoked.
• No signals found and no channels displayed, oscilloscope displays
and uses channel 1.
Table 3.2 – Auto Set Function Menu Items
Function
Setting
Acquire Mode
Adjusted to Sampling
Display Format
Y-T
Display Type
Set to Dots for a video signal, set to
Vectors for an FFT spectrum; otherwise,
unchanged
Vertical Coupling
Adjusted to DC or AC according to the
input signal
Bandwidth Limit
Off(full)
V/div
Adjusted
VOLTS/DIV adjustability
Coarse
