BK Precision 2190D User Manual

73
Set up Persist
Press “Persist” option button to select “Off”, “1 Sec”, “2 Sec”, “5 Sec” or
“Infinite”. You can use this option to observe some special waveforms.
Figure 3.37 – Persist Screen
Set up Intensity
Press the “Intensity” option button and turn the “Universal” knob
to adjust waveforms’ intensity.
Set up Brightness
Press the “Brightness” option button and turn the “Universal” knob
to adjust grid brightness.
Set up display format
1. Press the “Next Page” option button to enter second
display menu.
2. Press the “Format” option button to select “YT” or “XY”.
Set up Screen
Press the “Screen” option button to select “Normal” or “Inverted” to
set the screen display color.
Set up Grid
Press the “Grid” option button to select “ ”, “ ”or“
”to set the screen whether display grid or not.
Set up Menu Display
