CHAPTER 1: SPECIFICATIONS
1.1 GENERAL SPECIFICATIONS
TABLE 1-1. SPECIFICATIONS
SPECIFICATION DESCRIPTION
Approvals
Unit FCC, CE, CSA, RoHS, WEEE
Power Supply TUV, UL
Physical
LED Interface
(1) Power LED (green, located on front of the transmitters): Lights when power to the unit is ON;
(1) Power LED button (green, located on front of the receiver or manager): Lights when power to the unit is ON;
NOTE: Transmitter/Receiver or Manager turns on automatically and the LED lights when power to the unit is ON.
(1) RJ-45 Speed LED (green, located on top left of RJ-45 connector):
Blinks three times when the network connection is 1000 Mbps,
Blinks two times when network connection is 100 Mbps,
Blinks once when the network connection is 10 Mbps,
Not blinking: No Link to network;
(1) Activity LED (green, located on top right of RJ-45 connector):
Solid green: Link up,
Blinking: Activity on the link,
OFF: No link
Maximum Distance from CPU
to Transmitter
DTX1000-T, DTX1000SA-T, DTX1002-T: 16 ft. (5 m), DVI-D and USB limitations
Maximum Distance between
Transmitter and Receiver
328 ft. (100 m), use a network switch to get farther distances
Operating System Support
Microsoft Windows
®
Vista, XP, Windows 7, Windows 8, Windows 10, Server 2003, Server 2008, Server 2012, LInux
®
,
Solaris, Mac OS
Connectors
DTX1000-T: (1) DVI input, (1) USB Type B female, (1) RJ-45 network 10/100,
(1) 2.5-mm barrel connector for power;
DTX1000-R: (1) DVI output, (4) USB Type A female, (1) RJ-45 network 10/100,
(2) 3.5-mm connectors for microphone/stereo, (1) 2.5-mm barrel connector for power;
DTX1002-T: (2) DVI input, (1) USB Type B female, (1) RJ-45 network 10/100/1000,
(1) 2.5-mm barrel connector for power;
DTX1002-R: (2) DVI output, (4) USB Type A female, (1) RJ-45 network 10/100/1000,
(2) 3.5-mm connectors for microphone/stereo, (1) 2.5-mm barrel connector for power;
DTX1000SA-T: (1) DVI input, (1) USB Type B female, (1) RJ-45 network, (1) RJ-45 serial, (2) 3.5 mm audio,
(1) 2.5 mm barrel for power;
DTX1000SA-R: (1) DVI output, (4) USB Type A female, (1) RJ-45 network, (1) DB9 serial,
(2) 3.5 mm audio for SPK and MIC, (1) 2.5 mm barrel for power
DTX1032-R: (1) DVI output, (4) USB Type A female, (1) RJ-45 network 10/100/1000,
(2) 3.5-mm connectors for microphone/stereo, (1) 2.5-mm barrel coinnector for power
Dimensions
DTX1000-T, DTX1000-R, DTX1002-T, DTX1002-R, DTX1032-R: 1.38”H x 6.44”W x 4.31”D (3.5 x 16.35 x 10.94 cm);
DTX1000SA-T, DTX1000SA-R: 1.15"H x 6.2" W, 4.2"D (2.92 x 15.75 x 10.67 cm)
Weight
DTX1000-T, DTX1000-R, DTX1002-T, DTX1002-R, DTX1032-R: 0.85 lb. (0.38 kg);
DTX1000SA-T, DTX1000SA-R: 1.18 lbs (0.54 kg)
