PUT /audio/channel/{channelIndex}/input
Set the audio input for the selected channel
Parameter
Name Type Description
{channelIndex} integer
Name Type Description
input string
Possible values are: None, Camera - Left, Camera - Right,
Camera - Mono, XLR1 - Mic, XLR1 - Line, XLR2 - Mic, XLR2
- Line, 3.5mm Left - Line, 3.5mm Left - Mic, 3.5mm Right -
Line, 3.5mm Right - Mic, 3.5mm Mono - Line, 3.5mm Mono
- Mic.
Response
200 - OK
400 - Invalid input
404 - Channel does not exist
GET /audio/channel/{channelIndex}/input/description
Get the description of the current input of the selected channel
Parameter
Name Type Description
{channelIndex} integer
Response
200 - Description of the current input of the selected channel
The response is a JSON object.
Name Type Description
gainRange object
gainRange.Min number The minimum gain value in dB
gainRange.Max number The maximum gain value in dB
capabilities object
capabilities.PhantomPower boolean Input supports setting of phantom power
capabilities.LowCutFilter boolean Input supports setting of low cut filter
capabilities.Padding object
capabilities.Padding.available boolean Input supports setting of padding
capabilities.Padding.forced boolean Padding is forced to be set for the input
capabilities.Padding.value number Value of the padding in dB
404 - Channel does not exist
156Developer Information
