TIP Blackmagic Universal Videohub288 Crosspoint has amber colored LEDs
mounted inside the device that should only be visible when the heatsink is removed
for development purposes. However, in some cases a dim amber light may be visible
through the hole that has been drilled for the ‘alarm’ LED. This is not an error condition.
A healthy Universal Videohub288 Crosspoint should display the following:
Red ‘alarm’ LED Off.
Red ‘power overload’ LED Slowly blinking or off.
White ‘ref in’ LED Solid white or off.
Installing Interface cards
Installing a Universal Videohub SDI Interface or Universal Videohub Optical Interface is easy
and the steps are the same for installing each type of interface card.
1 Hold the card in a vertical orientation with the identification LED at the top of the card.
Theidentification LED looks like a pin hole near the top left of the top connector.
2 Gently insert the card along its guides until it plugs firmly into the PCI slot on the
motherboard.
3 Use a number 02 size Pozidriv screwdriver to secure the card to the Universal
Videohub frame.
See the ‘SDI Interface Card’ and ‘Universal Videohub Interface Cards’ sections for more
information on the different interface cards available for your Universal Videohub.
Installing a Universal Videohub Power Supply
The Universal Videohub Power Supply package consists of a power card, a power cable and
a 1RU chassis containing the power supply. A second Universal Videohub Power Supply can
be installed under the first power supply for failover redundancy. You will need to provide a
standard IEC cord with a C13 connector for each power supply.
1 Ensure that any new power supplies are disconnected from any electrical source. Orient
the power card so that the MAIN POWER label appears at the top of the card.
2 Insert the power card into either of the two power card slots.
3 Use a number 02 size Pozidriv screwdriver to secure the power card with its two screws.
Ifyou have a second power card, install it now into the spare power card slot.
4 Connect the power cable from the power card to the power supply. Tighten the thumb
screws on both power connectors. Repeat this step if you have a second power card
and second power supply. It does not matter which power card connects to which
power supply.
5 Connect an IEC cord from each power supply to a mains wall socket and turn on the power.
Congratulations! Your Universal Videohub288 is now ready to start routing video!
19Universal Videohub Routers
