Installing a Universal Videohub SDI Interface Card
MAIN POWER
+12V 800W
The Universal Videohub Power Supply consists of a power card which
is inserted into the Universal Videohub288 and then connected
to a 1RU chassis located under the Universal Videohub288
20Universal Videohub Routers
