SAM 950 Berkeley Nucleonics Corporation 12 of 62
CAMERA AND FLASH LIGHT
SAM 950 is equipped with built-in camera and a LED flash light for recording media information and
operation in dark environment.
✓ Push and hold (2 seconds) the ‘up-arrow’ button with a lamp icon (refer to the figure 3.4), the LED
flash light is turned ON. With same manner, the flash light is turned OFF.
Figure 3.4. Camera and flash light
TRIPOD ASSEMBLE GUIDE
SAM 950 can be mounted on a tripod. A tripod adaptor hole is located on the bottom of SAM 950 as
shown in figure 3.5.
Standard tripod screw shoe size is 3/8-16. Front and back hole are designed for 3x3 inch and 2x2 inch
(1.5x1.5 inch) detectors, respectively by considering weight balance.
