SAM 950 Berkeley Nucleonics Corporation 19 of 62
MAIN AND SUB- MENU STRUCTURE
Measurement status display, configuration, event log management, reach-back service, media file generation,
spectrum analysis, background measurement and calibration are all managed by the PDA and its application
software.
Intuitive, simple and hierarchical structure design of the new PeakAbout II software make the operation of
SAM 950 easy and flawless. In addition, function buttons on handle provides extra convenience in handling
the unit with wearing gloves.
Figure 4.4. and 4.5. graphically summarizes hierarchical structure of menus and describes how to use touch
screen or function buttons in order to surf between menus.
Figure 4.4. shows menu structure for event generation, manual ID and media file attachment procedure. And
Figure 4.5. covers structure for setup and event log management related tasks.
✓ Menu structure of manual ID and media file attachment
The main ‘Gauge’ ① and ‘Finder’ ② screen can be toggled by pressing up/down function
button or swiping up/down with a finger on the touch screen.
‘Manual ID’ screen ③ is access by press and hold key or touch ‘Manual ID’ menu on the
screen from the ‘Gage’ menu any time.
The ‘Spectrum’ ③ and ‘Classification’ ④ screen can be toggled by pressing left/right
function button or swiping left/right with a finger on the touch screen.
Stop ID and return to main screen by press button from either ‘Spectrum’ ③ or
‘Classification’ ④ screen. In this case, the event is deleted.
When manual ID is completed, ‘Event summary’ ⑤ screen is automatically popped-up. In this
screen, user can send the event to Reach-back ⑥ and/or RadResponder server ⑦ or attach media
files such as text/audio comment ⑨, photo(s) and video(s) ⑧.
Pressing button from the ‘Event summary’ ⑤ screen saves event data and returns to main
‘Gauge screen ①.
