BNC SAM 950 - Note and Photo

SAM 950 Berkeley Nucleonics Corporation 48 of 62
STEP 13. NOTE AND PHOTO
Text comments and/or photo/video may be attached to the opened event..
‘Attach text comment’ procedure is shown in figure 5.14.
1. Touch ‘EVENT INFO’ tab. ‘EVENT ID’ screen switches to ‘EVENT INFO’ screen.
2. Touch comment area. The keypad and typing window screen appeared.
3. Type in comments and touch ‘Done’ button.
Figure 5.14. Attach text comment procedure
‘Attach photo / Video / Recorder” procedure is described in figure 5.15
3. Touch “PHOTO/VIDEO /RECORDER” tab.
4. Touch menu key (Long press ). Then, Photo/Video /Recorder bar is showed up.
5. Touch “Photo” or “Video” or “Recorder” bar. Photo or Video or Recorder application is now
opened.
6. Take photo or video or recorder and touch “Save” button.
