8.4.1 Speed sensor 1
Connect the speed sensor tracks to the digital inputs S5IND (track A), S4IND (track B)
and S6IND (track Z).
The speed sensor type and the evaluation required are adjusted via the Operation
Mode
490 of speed sensor 1.
For a detailed description of possible settings refer to section 10.4.
Parameter
Settings
No.
Description
Min.
Max.
Fact.
490
Operation Mode speed sensor 1
Selection
491
Division Marks speed sensor 1
1
8192
1024
Dependent on the Operation Mode 490 of speed sensor 1 the digital inputs S4IND,
S5IND and S6IND are disabled for other functions. The functions will not be evaluated.
The actual speed and frequency of speed sensor 1 is displayed in Parameters
217
and
218.
8.4.2 Speed sensor 2
Speed sensor 2 must be connected to an expansion module. For connection, func-
tions and detailed parameter description refer to the applicable operation instructions
manual of the expansion module.
Parameter Settings
No.
Description
Min.
Max.
Fact.
493
Operation Mode speed sensor 2
Selection
494
Division Marks speed sensor 2
1
8192
1024
495
Level
Selection
The parameters 493, 494 and 495 are selectable dependent on the installed expan-
sion module.
Dependent on the Operation Mode 493 of speed sensor 2 some digital inputs of the
expansion module are disabled for other functions. The functions will not be evaluated.
The actual speed and frequency of speed sensor 2 is displayed in Parameters
219
and
220.
06/13 Operating Instructions ACU 115
