19.2 Actual Values of the Machine
The frequency inverter controls the behavior of the machine in the various operating
points. As a
function of the configuration selected and the expansion cards installed,
control variables and further actual value parameters of the machine can be dis-
played.
Actual Values of the Machine
No.
Description
Function
210 Stator Frequency
The output voltage (motor voltage) of the frequency
inverter.
211 R.m.s current
Calculated effective output current (motor current) of
the frequency inverter.
212 Output voltage
Calculated R.m.s. figure of the phase-to-phase volt-
age (motor voltage) of the frequency inverter.
213 Active power
Active power calculated from the voltage, the current
and the control variables.
214 Active current
Active current calculated from the rated motor pa-
rameters, the control variables and the current.
215 Isd
Current component of the field-orientated control
forming the magnetic flux.
216 Isq
Torque-forming current component of field-orientated
control.
217
Frequency Speed Sen-
sor 1
Calculated from the data on speed sensor 1, the No.
of pole pairs
373 and the speed sensor signal.
218
Speed sensor 1 speed
Calculation from speed sensor 1 frequency.
221 Slip frequency
Difference from the synchronous frequency calculated
from the rated motor parameters, the control varia-
bles and the current.
224 Torque
Torque at the current output frequency calculated
from the voltage, the current and the control varia-
bles.
225 Rotor flux
Current magnetic flux relative to the rated motor
parameters.
226 Winding temperature
Measured temperature of the motor winding ac-
cording to Operation mode 465 for temperature ad-
justment.
227 Act. rotor time constant
Time constant calculated for the operating point of
the machine from the rated motor parameters, the
rated and control variables.
235 Flux-forming voltage
Voltage component of the field-orientated control
forming the magnetic flux.
236 Torque-forming voltage
Voltage component of the field-orientated control
forming the torque.
238 Flux value
Magnetic flux calculated according to the rated values
and the operating point of the motor.
239 Reactive current
Reactive current calculated from the rated motor
parameters, the control variables and the current.
240 Actual speed Measured or calculated speed of drive.
241 Actual frequency Measured or calculated frequency of drive.
The actual values can be read out and monitored in the VAL menu branch of the oper-
ating unit. The parameter
Operation level 28
in the PARA menu branch defines the
selection of the actual value parameters to be selected.
260 Operating Instructions ACU 06/13
