15.5.4 Multiplexer/Demultiplexer
The multiplexer/demultiplexer enables the transfer of various digital signals between
an overriding controller and
frequency inverters via field bus or between frequency
inverters via the system bus. For parameterization of the multiplexer and demulti-
plexer using the VTable application, the commissioning and diagnosis software VPlus,
version 4.0.2 or higher is required.
The multiplexer features 16 inputs for logic signals or digital input signals.
On the output, the logic signal 927 -
Output MUX for the inputs of the TxPDO process
data of the system bus or for PZDx-IN process data of the Profibus can be used.
Operation mode Factory setting
1252 Mux inputs 7 -
Off
The parameters Mux input index (write) 1250 and Mux input index (read) 1251 for
the input signals of the multiplexer enable parameterization via the
control unit
KP500 or the application VTable in VPlus.
No. Description Min. Max. Fact. sett.
1250 Mux input index (write)
0 33 1
Non-volatile (fixed parameterization):
One Index of 1…16 in EEPROM
One Index of 1…16 in RAM
NOTE
The setting "0" for Mux input index (write) 1250 changes all data in EEPROM and
RAM.
In the case of non-volatile storage
(0…16), the changed values are still available
when power supply is switched on again.
In the case of volatile storage (17…33), the data is only stored in RAM. If the unit is
switched off, this data is lost and the data required are loaded from EEPROM afte
restart.
The demultiplexer features an input DeMux Input 1253 whose signal can be for the
process data RxPDO of the system bus or OUT-PZDx of Profibus.
On the output of the demultiplexer, the logic signals “910 - Output DeMux Bit 0”
to
“925 - Output DeMux Bit15” are available, e.g. for control of FT-instructions.
Operation modes for DeMux input 1253
9 -
Zero
704 … 727 -
RxPDO Word
740, 741 -
Remote control word, remote state word
910 … 925 -
Output DeMux Bit 0 ... output DeMux Bit 15
206 Operating Instructions ACU 06/13
