BONFIGLIOLI ACTIVE Cube ACU 201-01 User Manual

SETUP Selection 796
Function
33 -
Calc. and para ident.,
DS3
Additional motor data are measured, dependent
parameters are calculated and the parameter val-
ues are saved in data set 3.
34 -
Calc. and para ident.,
DS4
Additional motor data are measured, dependent
parameters are calculated and the parameter val-
ues are saved in data set 4.
40 -
Para-Ident. Machine
Data only, DS0
Additional motor data are measured and saved in
all of the four data sets.
41 -
Para-Ident. Machine
Data only, DS1
Additional motor data are measured and saved in
data set 1.
42 -
Para-Ident. Machine
Data only, DS2
Additional motor data are measured and saved in
data set 2.
43 -
Para-Ident. Machine
Data only, DS3
Additional motor data are measured and saved in
data set 3.
44 -
Para-Ident. Machine
Data only, DS4
Additional motor data are measured and saved in
data set 4.
110 -
Complete Setup w/o
Para-Ident., DS0
The auto set-up routine is performed in data set 0
and the parameter values are stored in all of the
four data sets identically. Extended motor data are
not measured.
111 -
Complete Setup w/o
Para-Ident., DS1
The parameter values of the auto set-up are stored
in data set 1. Extended motor data are not meas-
ured.
112 -
Complete Setup w/o
Para-Ident., DS2
The parameter values of the auto set-up are stored
in data set 2. Extended motor data are not meas-
ured.
113 -
Complete Setup w/o
Para-Ident., DS3
The parameter values of the auto set-up are stored
in data set 3. Extended motor data are not meas-
ured.
114 -
Complete Setup w/o
Para-Ident., DS4
The parameter values of the auto set-up are stored
in data set 4. Extended motor data are not meas-
ured.
The “additional motor data” also contain values of the current controller settings.
The individual steps of the auto set-up routine can be monitored and checked via
parameter SETUP Status 797. The
setup routine via the communication interface
continuously updates the status parameter which can be read out via the interface.
For the status message of the Auto set-up comply with
• Chapter 8.2.7 “Status messages during commissioning (SS…)”
• Chapter 8.2.8 “Warnings during commissioning (SA…)”
• Chapter 8.2.9 “Error messages during commissioning (SF…)”
06/13 Operating Instructions ACU 117
