The parameter Local/Remote 412 defines the operating behavior and enables a
change between the control via contacts or the control unit and/or the interface.
0 - Control via Contacts
The Start and Stop commands as well as the direction
of rotation are controlled via digital signals.
1 -
Control via state ma-
chine
The Start and Stop commands as well as the direction
of rotation are controlled via the DRIVECOM Statema-
chine of the communication interface.
2 -
Control via remote
contacts
The Start and Stop commands as well as the direction
of rotation are controlled via logic signals through the
3 -
dir. of rot. via con-
The Start and Stop commands are controlled from the
control unit and the direction of rotation is controlled
4 -
cont.,
dir. of rot. via con-
The Start and Stop commands are controlled from the
control unit or via digital signals. The statement of the
direction of rotation only with the help of the digital
5 -
Control 3-wire, dir. of
rot. via contacts
3-wire; control of direction of rotation and signal 3-wire
control
87 via contacts.
13 -
Control via keypad,
dir. of rot. via keypad
The Start and Stop commands as well as the direction
of rotation are controlled via the control unit.
14 -
cont.,
dir. of rot. via con-
The Start and Stop commands are controlled from the
control unit or via digital signals. The statement of the
direction of rotation only with the help of the operating
20 -
Control via cont.,
clockwise only
The Start and Stop commands are controlled via digital
signals. Fixed direction of rotation, clockwise rotation
23 -
Control via keypad,
clockwise only
The start and stop commands are controlled via key-
pad. Fixed direction of rotation, clockwise rotation only.
24 -
Control via cont. +KP,
clockwise rot. only
The Start and Stop commands are controlled from the
control unit or via digital signals. Fixed direction of rota-
tion, clockwise rotation only.
30 to 34
Operation mode 20 to 24, anticlockwise direction of
rotation only.
43 -
dir. of rot. via con-
The start and stop commands are controlled via digital
signals. The statement of the direction of rotation
comes from the operating unit or via digital signals.
44 -
sense of rot. via cont.
The Start and Stop commands as well as the sense of
rotation can be controlled from either the control unit
46 -
KP,
dir. of rot. via con-
3-wire and control unit; control of direction of rotation
and signal
3-wire control 87 via contacts or control
unit.
If the operation mode is changed while the drive is running, the drive will not be
stopped if no stop command is present in the new operation mode.
242 Operating Instructions ACU 06/13
