BONFIGLIOLI ACTIVE Cube ACU 201-01

Starting Behavior
No.
Description
Unit
Setting range
Chapter
620
Operation mode
-
Selection
12.1.1
621
Amplification
-
0.01 ... 10.00
12.1.1
622
Integral time
ms
1 ... 30000
12.1.1
623
Starting Current
A
0.0 ... o ⋅ I
FIN
12.1.1.1
624
Frequency Limit
Hz
0.00 ... 100.00
12.1.1.2
625 Brake release time ms -5000 … 5000
12.1.1.3
Warning application
626
Create Appl. Warning Mask
-
Selection
15.3.9
Stopping Behavior
630
Operation mode
-
Selection
12.2
Direct current brake
631 Braking current A 0.00 ... √2⋅I
FIN
12.3
632 Braking time s 0.0 ... 200.0
12.3
633
Demagnetizing time
s
0.1 ... 30.0
12.3
634
Amplification
-
0.00 ... 10.00
12.3
635
Integral time
ms
0 ... 1000
12.3
Stopping Behavior
637
Switch-off threshold
%
0.0 ... 100.0
12.2.1
638
Holding time
s
0.0 ... 200.0
12.2.2
Search Run
645 Operation mode - Selection
12.5
646 Brak. time after search run s 0.0 ... 200.0
12.5
647
Current / rated motor current
%
1.00 ... 100.00
12.5
648
Amplification
-
0.00 ... 10.00
12.5
649
Integral time
ms
0 ... 1000
12.5
Auto Start
651
Operation mode
-
Selection
12.4
PWM-/repetition frequency input
652
PWM-Offset
%
-100.00 … 100.00
14.11
653 PWM-Amplification % 5.0 … 1000.0
14.11
Slip compensation
660
Operation mode
-
Selection
17.4.1
661
Amplification
%
0.0 ... 300.0
17.4.1
662 Max. Slip Ramp Hz/s 0.01 ... 650.00
17.4.1
663 Minimum Frequency Hz 0.01 ... 999.99
17.4.1
Voltage controller
670
Operation mode
-
Selection
17.2
671 Mains failure threshold V -200.0 ... –50.0
17.2
672 Reference mains support value V -200.0 ... –10.0
17.2
673
Mains support deceleration
Hz/s
0.01 ... 9999.99
17.2
674
Acceleration on mains resumption
Hz/s
0.00 ... 9999.99
17.2
675
Shutdown threshold
Hz
0.00 ... 999.99
17.2
676 Reference shutdown value V
225 … 387.5 (201)
425 … 775 (401)
17.2
677 Amplification - 0.00 ... 30.00
17.2
678
Integral time
ms
0 ... 10000
17.2
680 Reference DC link limitation V
225 … 387,5 (201)
425 … 775 (401)
17.2
681
Max. frequency rise
Hz
0.00 ... 999.99
17.2
683
Gen. ref. current limit
A
0.0 ... o ⋅ I
FIN
17.2
06/13 Operating Instructions ACU 283
