BONFIGLIOLI ACTIVE Cube ACU 201-01

Motor connection ACU 401 (18.5 to 30.0 kW)
Connection of brake resistor with temperature switch
Star connection
V WU
Delta connection
V W
U
0.5 … 35 mm
AWG 20 … 2
2
18.5 kW … 30 kW
25/ 6-15,00
0.5 … 25 mm
AWG 20 … 4
2
1.00 … 25 mm
AWG 18 … 4
2
1.5 … 25 mm
AWG 16 … 4
2
X2
V W
U Rb2
Rb1
M
3~
X2
2.5 Nm
22.1 lb-in
0.5 … 35 mm
AWG 20 … 2
2
18.5 kW … 30 kW
25/ 6-15,00
0.5 … 25 mm
AWG 20 … 4
2
1.00 … 25 mm
AWG 18 … 4
2
1.5 … 25 mm
AWG 16 … 4
2
X2
2.5 Nm
22.1 lb-in
R
b
T1
Rb1 Rb2
T2
V WU
Rb2Rb1
X2
06/13 Operating Instructions ACU 65
