Cleaning and maintenance
EN
42 www.bora.com
Manual cleaning
u
Use a cleaner and degreaser in one.
u
Rinse the components with hot water.
u
Clean the components with a soft brush.
u
Rinse the components well after cleaning.
Cleaning in the dishwasher
u
Remove coarse food residues from the components.
u
Place the components in the dishwasher.
u
No water should be able to gather in the components.
u
Rinse the components with a rinsing program at a maximum
temperature of 65°C.
If the stainless steel grease filter can no longer be fully
cleaned, it must be replaced (Warranty, technical service,
spare parts, accessories).
7.2.6
Ending the cooktop extractor
cleaning process
To end the cleaning function, all grease filter components must be
correctly fitted.
u
Turn the knob ring or touch the control knob on the cooktop
extractor.
T
This deactivates the cleaning function.
T
The display on the control knob changes from C to 0 and the
cooktop extractor is ready for use.
T
If the grease filter or cover flap has not been properly fitted, the
error message ‘E012’, ‘E013’ or ‘FF out’ appears on the control
knob’s display (see"8Troubleshooting").
7.2.7
Replacing the recirculated air filter
In recirculation mode, an additional activated charcoal filter is used.
The activated charcoal filter absorbs cooking odours. The activated
charcoal filter is installed on the plinth fan or the duct system. If an
activated charcoal filter has reached the end of its service life, the
filter service display will appear and the filter must be replaced. After
replacing the filter, the filter service life must be reset.
u
Change the activated charcoal filter when the filter service display
appears.
T
You can see the service life and a description of how to change the
filter in the activated charcoal filter operating instructions.
u
Reset the filter service display (see"5.4.5Filter service life and
filter service display").
You can obtain activated charcoal filters from your specialist
supplier or from the BORA Shop via the website at http://
www.mybora.com.
7.3
Cleaning the cooktops
Any changes in colour or glossy spots do not mean that the cooktop
is damaged. They do not affect the functionality of the cooktop or the
stability of the glass ceramic panel.
Changes in the colour of the cooktop are the result of residues which
have not been removed and have burnt on.
Glossy spots are the result of wear by the pan base, especially if
aluminium-based cookware or unsuitable cleaning agents are used.
These are difficult to remove.
7.3.1
Cleaning glass ceramic cooktops
u
Make sure that the cooktop is switched off.
u
Wait until all cooking zones are cold.
u
Remove all coarse dirt and food residues from the cooktop using a
glass ceramic scraper.
u
Apply the cleaning agent to the cold cooktop.
u
Spread the cleaning agent using kitchen roll or a clean cloth.
u
Wipe the cooktop clean with a damp cloth.
u
Dry the cooktop with a clean cloth.
If the cooktop is hot:
u
Remove stubborn residues of plastic, aluminium foil, sugar or
sweet dishes from the hot cooking zone immediately using a glass
ceramic scraper to prevent burning.
Heavy soiling
u
Remove heavy soiling and marks (limescale marks, mother-of-
pearl-like shiny marks) using cleaning products while the cooktop
is still warm.
u
Wipe off any food that boils over with a damp cloth.
u
Remove any remaining dirt with the glass ceramic scraper.
u
Always remove any seeds, crumbs or similar that fall onto the
cooktop during cooking immediately to prevent the surface getting
scratched.
7.3.2
Cleaning Tepan stainless steel grill
surfaces
Any changes in colour or small scratches do not mean that the
cooktop is damaged. They do not affect the functionality of the
cooktop or the stability of the stainless steel grill surface. Changes in
the colour of the cooktop are the result of residues which have not
been removed and have burnt on.
Use the scraper only on the grill surface as otherwise other
surfaces may be damaged.
Clean stainless steel surfaces in the polishing direction only.
Do not apply citric acid to surfaces adjacent to the cooktop
and worktop as the acid may damage them.
Do not use stainless steel care products on the stainless steel
surfaces or the stainless steel grill surface.
Use the cleaning function to clean the Tepan stainless steel
grill.
Light soiling
u
Make sure that the cooktop is switched off.
u
Wait until the stainless steel grill surface has cooled.
u
Remove light soiling with a damp cloth and detergent.
u
To prevent water or limescale stains (yellowish colouring), use a
soft cloth to dry off the surfaces that have been cleaned with
water.
Normal soiling
u
Ensure that the cleaning function is activated for both grilling
zones.
u
Wait until the grilling zone indicators are no longer flashing (=
optimum cleaning temperature of 70°C).
u
Use only clean, cold water on the grill surface.
