3.2 System extension
The DICENTIS Conference System is scalable from small to medium to large. This section
describes what a small, medium and large system is and what the requirements are for these
systems:
A small to medium DICENTIS Conference System (see
Typical system setup, page 10
) consists
of:
– up to 450 DICENTIS nodes.
Refer to table Node and device count of DICENTIS equipment below about the node and
device count of DICENTIS equipment.
– all DICENTIS devices in 1 subnet.
– 1 DICENTIS Audio processor and powering switch for the audio processing.
– 1 Server PC which hosts the DICENTIS services.
A large DICENTIS Conference System consists of:
– up to 750 DICENTIS devices.
– multiple subnets connected by use of a router/L3 switch.
– Each subnet can have up to 450 DICENTIS nodes.
Refer to the following table for the node count of DICENTIS equipment.
– The first subnet has:
- 1 DICENTIS Audio processor and powering switch for the audio processing.
- 1 Server PC which hosts the DICENTIS services.
- 1 ARNI-Enterprise to increase the size of the system.
– All other subnets have 1 ARNI-Standard to increase the size of the system.
Note: There is no DICENTIS Audio processor and powering switch in the other
subnets.
Device Node count Device count
DICENTIS server 0 0
DICENTIS meeting application 0 0
DICENTIS Audio processor and powering switch 1 1
DICENTIS Powering switch 1 1
DICENTIS multimedia device 2 1
DICENTIS discussion device 1 1
DICENTIS discussion device select language 1 1
DICENTIS discussion device voting 1 1
DICENTIS discussion device extended 1 1
DCNM-IDESK Interpreter desk 1 1
DCNM-IDESKVID Interpreter desk with video 1 1
DCNM-FSL Flush language selector 1 1
OMN-DANTEGTW Dante gateway 1 0
PRS-4OMI4 OMNEO media interface 1 0
OMN-ARNIE ARNI‑E OMNEO interface 0 1
