5.0 Programming
2. Press [1] to select 1: EVENTS. The window shows:
4/2 POINT RPT
1: FIRE ALRM D1
2: FIRE RSTR D1
3: WATERFLOW D1
4: SUPERVISE D1
5: TROUBLE D1
6: TRBL RSTR D1
7: DISABLE D1
8: DSBL RSTR D1
9: MONITOR D1
3. D1 refers to Digit #1. Press the number key that
corresponds with your selection of event type. In
this example, 1: FIRE ALRM D1 is selected. The
window shows:
FIRE ALRM D1 (_____)
0-9, <TEST>:
4. The current setting appears in parentheses on the
first line. Press [# Command] to verify your
selection.
5. If you prefer to assign a hexadecimal value, press
[Test]. The window shows:
SELECT HEX CODE
1: HEX A
2: HEX B
3: HEX C
4: HEX D
5: HEX E
6: HEX F
In 4/2 formats, HEX a reports as 0 (zero).
6. Press the number key that corresponds with your
selection.
7. Press [# Command] to verify the selection. Press [*
Clear] to return to the 4/2 Point Rpt Submenu.
8. At the 4/2 Point Rpt Submenu, press [2] to select
ZONES 1 TO 9 and assign the event type to a
point. The window shows:
4/2 POINT RPT
1: ZONE 1 D2
2: ZONE 2 D2
3: ZONE 3 D2
4: ZONE 4 D2
5: ZONE 5 D2
6: ZONE 6 D2
7: ZONE 7 D2
8: ZONE 8 D2
9: ZONE 9 D2
9. D2 refers to #2. Press the number key for the zone
that corresponds with your event type selection. In
this example, Zone 2 is selected. Refer to Figure 17
on page 24 for details. The window shows:
ZONE 2 D2 (__)
0-9, <TEST>:
10. The current setting appears in parentheses on the
first line. Press [# Command] to verify your
selection.
11. If you prefer to assign a hexadecimal value, press
[Test]. The window shows:
SELECT HEX CODE
1: HEX A
2: HEX B
3: HEX C
4: HEX D
5: HEX E
6: HEX F
12. Press the number key that corresponds with your
selection.
13. Press [# Command] to verify the selection. Then
press [* Clear] to return to the 4/2 Point RPT
Submenu.
If you want to assign an event type to Point
(Zone) 10, choose [3]-ZONE 10 D2 on the
4/2 Point Rpt Submenu and follow the
preceding instructions for Zones 1 to 9.
2: RPT CODES
To access RPT CODES, select [0]: PROGRAM--->
[6]: PROG FORMATS--->[2]: 4/2 RPT CODES. The
4/2 Report Codes apply to the system conditions only
when the 4/2 format is selected. You can program two
digits to be sent for each condition. Refer to Appendix B
on page 47 for a description of each 4/2 Report Code
that is supported by the FPT-DACT.
