1/05 | F01U002505B
EN | 42FPT-DACT | Operation & Installation Guide |
5.0 Programming
To set report codes for system conditions:
1. At the Prog Formats Submenu, press [2] to select
2: 4/2 RPT CODES. The window shows:
4/2 RPT CODES
1: GROUP 1
2: GROUP 2
3: GROUP 3
4: GROUP 4
5: GROUP 5
2. The 4/2 reporting codes are divided into five
groups. Press the number key that corresponds with
your selection. In this example, 1: GROUP 1 is
selected. The window shows:
4/2 RPT CODES
1: SYSTM IN TST
2: SYS TEST RST
3: SILENCE
4: FIRE DRILL
5: FIRE DRL RST
6: OPEN RST RPT
7: LOW BATTERY
8: LOW BATT RST
9: AC FAILURE
3. Press the number key that corresponds to your
selection. In this example, 1: SYSTM IN TST is
selected. The window shows:
SYSTM IN TST (___)
0-9, <TEST>:
4. The current setting appears in parentheses on the
first line. Using the keypad, enter a value from 1 to
9, or press [Test] for a list of hexadecimal entries.
Pressing [Test] shows the window:
SELECT HEX CODE
1: HEX A
2: HEX B
3: HEX C
4: HEX D
5: HEX E
6: HEX F
Use the programming procedure for 4/2
reporting codes in Groups 2 to 5.
Refer to Appendix A on page 45 for
definitions of each 4/2 reporting code.
3: SIA SILENC RPT
To access SIA SILENC RPT, select [0]: PROGRAM
--->[6]: PROG FORMATS--->[3]: SIA SILENC RPT.
When using SIA reporting, all reporting codes except
one are fixed and do not require programming. The
Silence Report is not a standard SIA code and can be
programmed.
Use hexadecimal numbers to enter the required ASCII
value. Enter one number for the left character or byte
and another number for the right character or byte.
Use the factory default KB = 0B x 4B, 0B x 42B.
Refer to a standard table of ASCII values. All data that
is entered consists of hexadecimal values. The SIA event
codes use characters ranging from A to Z.
To program SIA event codes for the Silence Report:
1. At the Prog Formats Submenu, press [3] to select
3: SIA SILENC RPT. The window shows:
SIA SILENC RPT
1: LEFT BYTE
2: RIGHT BYTE
2. Press the number key that corresponds with your
selection. In this example, 1: LEFT BYTE is
selected. The window shows:
LEFT BYTE (___)
0-9, <TEST>:
3. The current setting appears in the parentheses on the
first line. Enter a hexadecimal value and press
[# Command].
4. To view the hexadecimal codes, press [Test]. The
window shows:
SELECT HEX CODE
1: HEX A
2: HEX B
3: HEX C
4: HEX D
5: HEX E
6: HEX F
Program 2: RIGHT BYTE using the same
procedure as programming SIA event codes
for the Silence Report.
