Bosch FSA 500 User Manual

1 689 989 115 2013-08-30| Robert Bosch GmbH
26 | FSA 500 | Product descriptionen
3.5.6 Measurement lead with voltage divider
The measurement lead with voltage divider
(1 687 224 301) is used for voltage measurements up
to 60VDC/30VAC/300VACpeak. The accessory set
(1687 016 118) contains test prods (1684485434/
... 435) and pick-off clips (1684480403/ ... 404) as
accessories for the measurement lead with voltage
divider. Never use the measurement lead with voltage
divider to measure mains or similar voltages.
3.6 Bluetooth
3.6.1 Bluetooth USB adapter
Only the Bluetooth USB adapter included in the scope
of delivery provides a radio link with the FSA 500. It is
plugged in at the PC/Laptop. Readiness for operation is
indicated by the flashing blue LED.
! It is not possible to operate any other item of Blue-
tooth hardware fitted or plugged into the PC/Laptop,
as this would interfere with data communication
between the FSA 500 and the PC/Laptop.
! Do not subject the Bluetooth USB adapter connected
to the Laptop to mechanical strain or use it as a
handle, as this could damage the Laptop or Blue-
tooth USB adapter.
3.6.2 Key to Bluetooth symbols
Bluetooth Manager symbol (in task bar):
Color Function
Green Bluetooth USB adapter active and communi-
cating with FSA 500.
White Bluetooth USB adapter plugged into PC/Laptop
but Bluetooth link not active.
White / green
(7-second
frequency)
Bluetooth USB adapter attempting to establish
radio link with FSA 500.
Red Bluetooth USB adapter not plugged
in at PC/Laptop.
Bosch Bluetooth Device symbol (in toolbar):
Color Function
Green Field strength of Bluetooth wireless link OK.
Red Field strength of Bluetooth wireless link too
low. Reduce distance between Bluetooth
USB adapter and FSA 500 or avoid obstacles
such as e. g. steel doors or concrete walls.
Symbol miss-
ing
No Bluetooth wireless connection.
Follow the instructions in chapter 2.6.
i With the FSA 500, the USB connection can be acti-
vated and used if the Bluetooth link is interrupted.
3.7 Notes concerning faults
i Please see the notes in section 2.6 and 3.6.2.
FSA 500 has found via Bluetooth.
Possible causes What can you do
No external voltage
supply.
Check if FSA 500 is supplied with exter-
nal power.
LED B on FSA 500 must light up violet or
green (see section 3.5.4).
FSA 500 not
active or incorrectly
configured.
1. Select the "Settings" test step.
2. Check in "Settings" if FSA 500 is con-
nected correctly.
Bluetooth connec-
tion faulty or miss-
ing (e.g. according
to standby model of
the PC/Laptop).
Bluetooth Manager symbol white, white/
green or red.
1. Shorten distance between PC/laptop
with Bluetooth USB adapter and FSA 500.
2. Unplug the Bluetooth USB adapter and
plug in again or re-boot the PC/laptop.
No Bluetooth USB
adapter.
Bluetooth manager symbol red.
1. Plug in Bluetooth USB adapter.
2. Restart FSA 500.
