6. Maintenance
6.1 Cleaning
The housing of the FSA 500 is only to be cleaned with a
soft cloth and neutral cleaning agents. Do not use abra-
sive cleaning agents and coarse workshop cloths.
6.2 Replacement and wearing parts
Designation Order number
FSA 500 0 684 010 530
Power supply unit
with power cord
1 687 023 592
1 684 461 106
USB connecting cable (3 m)
<)
1 684 465 562
Secondary measuring transducer
<)
1 687 225 017
Clip-on trigger
<)
1 687 225 018
Primary connecting cable (UNI 2)
<)
1 684 461 185
Multi measurement lead CH1
<)
1 684 460 288
Multi measurement lead CH2
<)
1 684 460 289
Measurement lead with voltage divider 1 687 224 301
Current probe 1000 A
<)
1 687 225 019
Coupling with hose 1 686 430 053
Remote trigger 1 684 463 828
Connecting cable B+/B–
<)
1 684 460 286
Passenger vehicle temperature sensor
<)
1 687 230 068
Connection terminal, black
<)
1 684 480 022
Bluetooth USB adapter 1 687 023 449
Case 1 685 438 644
Test prod set
<)
1 684 485 362
Accessory set with
Black and red test prods
Black and red pick-off clips
Black, red, gray adapter connectors
1 687 016 118
Battery pack
<)
1 687 335 039
<)
Wearing parts
7. Decommissioning
¶ Disconnect the FSA 500 from the mains.
7.1 Temporary shutdown
In the event of lengthy periods of non-use:
7.2 Change of location
¶ If the FSA 500 is passed on, all the documentation
included in the scope of delivery must be handed over
together with the unit.
¶ The FSA 500 is only ever to be transported in the
original or equivalent packaging.
¶ Unplug the electrical connection.
¶ Heed the notes on initial commissioning.
7.3 Disposal and scrapping
The FSA 500 is subject to the European
directive 2002/96/EC (WEEE).
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
¶
Make use of the local return and collection
systems for disposal.
¶ Proper disposal of the FSA 500 prevents
environmental pollution and possible
health hazards.
1. Disconnect the FSA 500 from the mains and detach
the power cord.
2. Dismantle the FSA 500 and sort out and dispose of
the different materials in accordance with the ap-
plicable regulations.
