1 689 989 115 2013-08-30| Robert Bosch GmbH
Technical data | FSA 500 | 31 en
8. Technical data
8.1 Dimensions and weights
Property Value/Range
Dimensions (W x H x D) 200 x 280 x 110 mm
7.9 x 11.0 x 4.3 inch
Weight (without accessories) 1,5 kg
3.3 lb
8.2 Specifications
Property Value/Range
Rated voltage U(V) 19 DC
Rated power P(W) 60
Degree of protection IP 30
8.3 Temperature, humidity and
atmospheric pressure
8.3.1 Ambient temperature
Property Value/Range
Storage and transportation 5 °C – 40 °C
41 °F – 104 °F
Operation 5 °C – 40 °C
41 °F – 104 °F
Measurement accuracy 10 °C – 35 °C
50 °F – 95 °F
Battery charging temperature 0 – 45°C
8.3.2 Humidity
Property Value/Range
Storage and transportation 30 % – 60 %
Operation 20 % – 80 %
Measurement accuracy 30 % – 60 %
8.3.3 Atmospheric pressure
Property Value/Range
Storage and transportation 700 hPa – 1060 hPa
Operation (at 25 °C and 24 h) 700 hPa – 1060 hPa
Measurement accuracy 700 hPa – 1060 hPa
8.4 Noise emissions
< 70 dB(A)
8.5 Power supply unit
Property Value/Range
Frequency 50 Hz – 60 Hz
Input voltage (AC) 100 V~ – 240 V~
Input current 1,5 A
Output voltage (DC) 19 V
Output current 3,7 A
8.6 Battery
Property Value/Range
Battery life < 4 h
Charging time for battery capacity
> 70 %
(with battery flat and FSA 500
switched off; charging time increas-
es with parallel measurements)
< 1 h
8.7 Bluetooth Class 1 and 2
Radio link Class 1 (100 mW) Minimum range
Free field workshop environment 30 m
For measurements in vehicle engine
compartment
10 m
Radio link Class 2 (10 mW) Minimum range
Free field workshop environment 3 m
For measurements in vehicle engine
compartment
1 m
8.8 Signal generator
Function Specification
Amplitude - 10 V – 12 V
(load < 10 mA) to ground
Signal forms DC, sinusoidal, triangular,
square-wave
Frequency range 1 Hz – 1 kHz
Max. output current 75 mA
Impedance approx. 60 Ohm
Symmetry 10 % – 90 %
(triangular, square-wave)
Curve generation Output rate up to
100000 values/s,
resolution 8 bit,
Y full range adjustable
(bit), unipolar / bipolar
operation
Short-circuit proof with respect
to interference voltage, static
< 50 V
Short-circuit proof with respect
to interference voltage, dynamic
< 500 V / 1 ms
Additionally:
R Automatically activated filters and attenuators
forenhanced signal quality.
R Automatic shut-off in the case of short circuit,
detection of interference voltage on starting signal
generator.
