1 689 989 115 2013-08-30| Robert Bosch GmbH
32 | FSA 500 | Technical dataen
8.9 Measurement functions
8.9.1 Engine test
Measurement functions Measuring ranges Resolution Sensors
Speed 450 min
-1
– 6000 min
-1
100 min
-1
– 12000 min
-1
250 min
-1
– 7200 min
-1
100 min
-1
– 500 min
-1
10 min
-1
10 min
-1
10 min
-1
10 min
-1
Connecting cable B+/B–
Clip-on trigger, secondary sensor,
Primary connecting cable (UNI2)
Current probe 30 A, diesel clip-on sensor,
current probe 1000 A (starter current)
Oil temperature -20 °C – 150 °C 0,1 °C Oil temperature sensor
U-Battery 0 – 60 V DC 0.1 V Connecting cable B+/B–
U-Term. 15 0 – 60 V DC 0.1 V Primary connecting cable (UNI2)
U-Term. 1 0 –10 V
0 – 20 V
10 mV
20 mV
Primary connecting cable (UNI2)
Ignition voltage,
spark voltage
±50 kV
±10 kV
1 kV
0,1 kV
Primary connecting cable (UNI2),
secondary sensor
Spark duration 0 – 10 ms 0,01 ms Primary connecting cable (UNI2),
secondary sensor
Relative compression over starter current 0 – 200 Ass 0,1 A Primary connecting cable (UNI2),
secondary sensor
U-Alternator ripple 0 – 200 % 0.1 % Multi measurement lead CH1
I-Starter
I-Alternator
I-Glow plugs
0 – 1000 A 0.1 A Current probe 1000 A
I-Primary 0 – 30 A 0.1 A Current probe 30 A
Dwell angle 0 – 100 %
0 – 360 °
0,1 %
0,1 °
Primary connecting cable (UNI2)
Dwell period 0 – 50 ms
50 ms – 100 ms
0,01 ms
0,1 ms
Secondary sensor
Current probe 30 A
Pressure (atmospheric) -800 hPa – 1500 hPa 1 mbar Atmospheric pressure sensor
Duty cycle 0 – 100 % 0.1 % Multi measurement lead CH1 / CH2
Injection time 0 – 25 ms 0.01 ms Multi measurement lead CH1 / CH2
Pre-heating time 0 – 20 ms 0.01 ms Multi measurement lead CH1 / CH2
8.9.2 Multimeter
Measurement functions Measuring ranges Resolution Sensors
Speed As for engine test
U-Battery 0 – 60 V DC 72 mV Connecting cable B+/B–
U-Term. 15 0 – 60 V DC
1)
72 mV Primary connecting cable (UNI2)
U-DC
min./max.
±200 mV – ±20 V
±20 V – ±200 V
1)
0.001 V
0.01 V
Multi measurement lead CH1 / CH2
I-1000 A ±1000 A 0.1 A Current probe 1000 A
I-30 A ±30 A 0.01 A Current probe 30 A
Resistance
(R-Multi 1)
0 – 1000 Ω
1 kΩ – 10 kΩ
10 kΩ – 999 kΩ
0.001 Ω
0.1 Ω
100 Ω
Multi measurement lead CH1
Pressure P-Air -800 hPa – 1500 hPa 2,5 hPa Atmospheric pressure sensor
Pressure P-Fluid 0 – 1000 kPa 0,25 kPa
Oil temperature -20 °C – 150 °C 0,2 °C Oil temperature sensor
Air temperature -20 °C – 100 °C 0,1 °C Air temperature sensor
Diode test
R Test voltage
R Test current
max. 4,5 V
max. 2 mA
Continuity test 0 – 10 Ohm
1)
The measuring range is greater than the permissible measurement voltage
