Operation
6.16.2.1 Using the SR Suntour low-speed compression damping
Low-speed movement in the suspension fork is
caused, for example, by riding over bumps.
The settings of the low-speed damper control the
suspension behaviour of the fork
• during staggered jumps
• during shifts in the rider's body weight
• when force is applied slowly.
Figure 167: Low-speed movements
 Turn low-speed lever (1) on the fork crown
gradually in a clockwise direction.
 The low-speed compression damper is placed
in a harder setting.
 Turn low-speed lever (1) on the fork crown
gradually in an anticlockwise direction.
 The low-speed compression damper is placed
in a softer setting.
R2C2-PCS
R2C2
RC2
RC2-PCS
RC-PCS
RC
RLRC-PCS
RLRC
LORC-PCS
LORC
Table 70: Low-speed lever (1) on the SR Suntour suspension fork on the fork crown
1
1
1
1
