Description
3.3.8.5 Frame battery
Three different types of frame batteries can be
fitted:
Figure 59: Overview of frame battery
Figure 60: Details of frame battery
1 Battery housing
2 Battery lock
3 Battery key
4 On-off button (battery)
5 Battery level indicator (battery)
6 Charging port cover
7 Charging port
PowerPack 300 PowerPack 400 PowerPack 500
1
2
4
5
6
7
3
