18 en | Installation NurseCall Main Unit
F.01U.252.699 | V1.1 | 2012.01 User Manual Bosch Security Systems
3.2.7 Setting the jumpers on the communication board
1. Disassemble the unit; see Section 7.5.1 Disassembling the unit, page 48.
2. Remove the communication board; see Section Removing the communication board,
page 48.
3. Set the jumpers as required in your configuration. By default the jumpers are set for
connection to a DECT phone system.
Setting the jumpers for a DECT phone system, Alarm Management Software, NPS
programming or Medicall 800:
Setting the jumpers for Paging systems (except Medicall 800) and printers:
4. Assemble the communication board and the unit. This is basically the reverse of the
disassembling procedure, see Section 7.5.1 Disassembling the unit, page 48.
