Voice Alarm Router
Electrical
Mains voltage: 230/115 V(AC), ± 10%, 50/60 Hz
Mains current: 0.2 A (system idle)
0.3 A (maximum load)
Max. mains inrush current: 1.5 A (for mains voltage of 220 - 240 V)
3 A (for mains voltage of 100 - 120 V)
Battery voltage: 20.0 to 26.5 V(DC)
Battery current: 0.5 A (system idle)
1.5 A (maximum load)
Notice!
Maximum load means maximum power out, maximum load 24 V(DC) out and maximum
number of call stations.
Interconnection
Voice Alarm Router: RJ45 socket, CAN bus; max. 2 routers
External power amplifiers: 3-pin XLR and screw terminals, max. 5 A;
max. rated output 1000 W
Loudspeaker outputs
Type: Screw terminals
Number of zones: 6
Number of loudspeaker lines: 12 (2 per zone)
Signal-to-noise ratio (flat at max. volume): > 85 dB
Line voltage: 100 V
Overrides
Type:
3‑wire or 4‑wire on screw terminals
Voltage: 24 V(DC) for 4‑wire, if selected
Current: Total 0.8 A
Trigger inputs / 24 V DC out
Trigger voltage:
< 24 V
Type:
Momentary or latching
Normally opened (default) or normally
closed
Emergency input supervision: 10 kΩ + 10 kΩ series and parallel resistors
24 V DC out: 24 V(DC), max. 0.8 A
10.1.2
Plena Technical data | en 109
Bosch Security Systems B.V. Installation and Operation manual 2013.07 | V2.0 |
