Bosch Rexroth MS2N User Manual

Motor encoder MS2N ‑Availability according to motor frame size
Motor frame size
Encoder
AM AS BM BS CM CS HM HS DM DS
MS2N03 ● ● ● ● ● ● ● ● - -
MS2N04 ● ● ● ● ● ● ● ● - -
MS2N05 ● ● ● ● ● ● ● ● - -
MS2N06 ● ● ● ● ● ● ● ● - -
MS2N07 ● ● ● ● ● ● - - ● ●
MS2N10 ● ● ● ● ● ● - - ● ●
MS2N13 ● ● ● ● ● ● - - ● ●
● available | - not available
Tab. 4-6: Available motor encoder according to motor frame size
Motor encoder MS2N ‑ Electrical connection (available options)
Connection technique
Encoder
AM AS BM BS CM CS HM HS DM DS
Single cable connection (S) - - - - ● ● ● ● ● ●
Double cable connection (A, B, C, D, E, T, U,
V)
● ● ● ● ● ● ● ● ● ●
● available | - not available
Tab. 4-7: Available connection technology for MS2N encoder
MS2N Synchronous Servomotors 21/101
