Bosch Rexroth REFUspeed RS51 - Dimension Drawing, Side View, Sizes J to M

4-4 Mounting REFUspeed RS51
DOK-RD500*-RS51*******-IB02-EN-P
Dimension drawing, side view, sizes J to M
320
Hot discharged air
Cooling air
320
Hot discharged air
Cooling air
Fig. 4-4: Dimension drawing, side view GK J to M
