REFUspeed RS51 Basic parameterization 7-13
DOK-RD500*-RS51*******-IB02-EN-P
Parame-
ter No.:
Name Description / explanation
selectable options
Factory setting
min ... max values
Pass
wor
d
0890 Ref., analogue output Reference, analogue output +10V reference
output
1
0 = +10V reference output
1 = -10V reference output
2 = fact output frequency
3 = Iact output current (apparent current)
4 = Isq torque-generating (active current)
5 = Vact output voltage
6 = Pact output power
7=Pactiveactivepower
0...7
0221.00 PT1 filt. timeconst Supplementary parameter for “analog output”.0ms 1
To smooth any value which is connected at the analog
output.
0 ... 10000 ms
0559 Pactual PT1 time Supplementary parameter for “analog output”.50ms 1
Only to smooth the Pact value. 0 ... 10000 ms
0560 Ptrue PT1 filter time Supplementary parameter for “analog output”.50ms 1
Only to smooth the Pactive value. 0 ... 10000 ms
0411 Output-block signal Supplementary parameter for “analog output”.Direct 1
Defines how a signal is transferred.
0=direct
1 = absolute value
2=inverted
3 = absolute value, inverted
0...3
0413 Output-block, norm. Supplementary parameter for “analog output”. 100.00 % 1
Normalization of the analog output 10 V correspond to
the value set here.
6.26 ... 200.00 %
0561 Output-block Supplementary parameter for “analog output”. 0.. ±100 % 2
0=0...±100%
1=+20...+100%
0/1
0412 Output-block offs. Supplementary parameter for “analog output”.0.00% 1
Offset -100.00 ... 100.00
%
