Bosch Rexroth REFUspeed RS51 - Type Code; Type Code, Basic Drive

REFUspeed RS51 Description 3-7
DOK-RD500*-RS51*******-IB02-EN-P
3.5 Type code
Type code, basic drive
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05
Beispiel:
Kurztext-
Spalte
RS51 . 1 - 4G-003- L -NN- FW
1. Product group
1.1 RS. . . . . . . . . . . . = RS
2. Line
2.1 U/f curve control = 51
3. Design
3.1 1 . . . . . . . . . . . . . . . . . . . . . . . = 1
4.
Unit type / Nominal connecting voltage
4.1 Umrichter 3 x AC 380480 V, ±10 % = 4
5. Brake chopper for converter
5.1 with built-in brake chopper and
resistor . . . . . . . . . . . . . . . . . . . . = G
6. Rated power data (kVA)
3 6 14 24 31 50
z.B. 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 003
7. Cooling mode
7.1 forced air cooling . . . . . . . . . . . . . . . . . . . . . . . . . = L
8. Additional functions
8.1 not equipped . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NN
8.2 24 V stand-by power, external . . . . . . . . . . . . . . . . . . . = V1
9. Firmware
9.1 Denotes that firmware must be ordered as separate subposition = FW
Note:
All converters are equipped with mains filter.
with operating mode S6, operating factor 60 % (T = 120 s)
1
2
1
2
Fig. 3-5: Type code, basic drive
