7-4 Basic parameterization REFUspeed RS51
DOK-RD500*-RS51*******-IB02-EN-P
7.2 Password levels
The parameters are located on various access levels. A password is re-
quired to change parameters. If several parameters were changed in the
parameterization, the password only has to be entered for the first time.
The password level required can be seen from the parameter table.
Password not required
Esc
,
Mon
,
Prog
and then acknowledge with
Enter
Esc
,
Mon
,
Prog
, and then acknowledge with
Enter
,
Esc
,
Mon
,
Prog
and then acknowledge with
Enter
.
All of the parameters of the lower password level are then acceptable
using the selected password.
7.3 Quick-Setup
Parame-
ter No.:
Name Description / explanation
selectable options
Factory setting
min ... max values
Pass
wor
d
0010 Language Selects the display language:
0=German
1 = English
German
0/1
0
0100.XX Motor type Selects the motor type:
0 = Induction motor ASM
1 = Synchronous motor SM
Induction motor
ASM
0/1
2
0101.XX Rated speed ASM
Rated speed from the motor rating plate.
2)
1)
100 ... 95000 RPM
2
0102.XX Rated frequency
ASM
Rated frequency from the motor rating plate.
2)
1)
10.0 Hz... P0099
2
0103.XX Rated current ASM
Rated current from the motor rating plate.
2)
1)
1.00 A... P0033
2
0104.XX Rated voltage ASM
Rated voltage from the motor rating plate.
2)
1)
10 ... 600 V
2
0106.XX cos-phi ASM
cos-phi from the motor rating plate.
2)
1)
0.50 ... 0.98
2
0112.XX Rated current SM
Rated current from the motor rating plate.
3)
1)
1.00 A... P0033
2
0113.XX Rated speed SM
Rated speed from the motor rating plate.
3)
1)
100 ... 95000 RPM
2
0105.XX Voltage constant SM
Voltage constant from the motor rating plate.
3)
1)
0.01 ... 50.00 V/Hz
2
0107.XX Pole number SM
Pole number from the motor rating plate.
3)
1 ... 64
2
0178.XX f limit, motor
Highest permissible motor frequency (protection
against centrifugal force).
The maximum output frequency is limited, as a func-
tion of the pulse frequency, to the value of P0027.
When changing the motor rating plate data, P0178 is
set to the rated motor frequency plus 5%.
50.00 Hz
0.0 Hz ...P0027
2
Password 0
Password 1
Password 2
Password 3
