Bosch Rexroth REFUspeed RS51 User Manual

REFUspeed RS51 Electrical installation 5-9
DOK-RD500*-RS51*******-IB02-EN-P
X 80 start inhibit
X 2 motor connection
X 83 supplementary
function P24V
standby supply
X1 brake resistor and
DC link
X1 line supply
connection
Fig. 5-5: Terminal layout diagram GK M
