5-20 Electrical installation REFUspeed RS51
DOK-RD500*-RS51*******-IB02-EN-P
REFUspeed RS51 REFU 316 F Function
Terminal Designation Module Terminal Module
X17.6 Dig In 8 SR17000 X2.12 Terminal
Par. set selection, weighting 2
0
X17.7 Dig In 11 SR17000 X2.15 Terminal
Par. set selection, weighting 2
3
X14.8 An Out SR17000 X2.16 Terminal +10V reference voltage for the potentiometer
X14.9 An In+ SR17000 X2.17 Terminal Analog setpoint +
X14.10 An In- SR17000 X2.18 Terminal Analog setpoint -
X14.11 SR17000 X2.19 Terminal Reference point 0V reference voltage
X16.1 S Rel Out SR17000 X2.27 Terminal Fault signal, relay 250V / 1A
X16.2 C Rel Out SR17000 X2.26 Terminal
X16.3 Ö Rel Out SR17000 X2.25 Terminal
X15.1 + PTC/KTY+ SR17000 X2.20 Terminal Motor protection, PTC evaluation
X15.2 - PTC/KTY- SR17000 X2.21 Terminal
X31.1 KL17037 Terminal
X31.6 KL17037 Terminal
0V digital reference point
free reference point for X31.2..5
possibly connect with X31.1.
X31.2 Opt Dig In 1 KL17037 X2.42 Terminal Source block changeover TEST / NORMAL
X31.3 Opt Dig In 2 KL17037 X2.37 Terminal f min selection
X31.4 Opt Dig In 3 KL17037 X2.7 Terminal
Setpoint voltage selection2 (A..D) 2
0
X31.5 Opt Dig In 4 KL17037 X2.40 Terminal
Setpoint voltage selection2 (A..D) 2
1
X32.1 S Opt Rel Out 1 KL17037 Relay 1, can be freely configured
X32.2 C Opt Rel Out 1 KL17037 Relay 1
X32.3 S Opt Rel Out 2 KL17037 Relay 2, can be freely configured
X32.4 C Opt Rel Out 2 KL17037 Relay 2
X32.5 Ö Opt Rel Out 3 KL17037 Relay 3, can be freely configured
X32.6 C Opt Rel Out 3 KL17037 Relay 3
X32.7 S Opt Rel Out 3 KL17037 Relay 3
X32.8 Ö Opt Rel Out 4 KL17037 Relay 4, can be freely configured
X32.9 C Opt Rel Out 4 KL17037 Relay 4
X32.10 S Opt Rel Out 4 KL17037 Relay 4
X33.1 Opt An Out 1 KL17037 Analog output 1, can be freely configured
X33.2 Opt An Out 2 KL17037 Analog output 2, can be freely configured
X33.3 KL17037 0V analog reference point
X34.2 Opt An In+ KL17037 X56.7 WM4034 Sensitivity or load limit +
X34.1 Opt An In- KL17037 X56.8 WM4034 Sensitivity or load limit -
