Bosch ZEMO SU-E FS 12 - Grip Distance on a SHIMANO ST-EF41 Brake Lever

MY22Z0a - 12_1.0_25.07.2022
125
Operation
6.5.9.6 Grip distance on a SHIMANO ST-EF41 brake lever
Only applies to pedelecs with this equipment
The brake lever position can be adjusted to the
rider's requirements. Such adjustment does not
affect the pressure point or the position of the
brake linings.
 Turn setting screw anti-clockwise towards
minus (–).
 The brake lever moves closer to the handlebar
grip.
 Turn setting screw clockwise towards plus (+).
 The brake lever moves away from the
handlebar grip.
Figure 138: Setting screw position (1)
1
