3.3.4.4 RockShox rear frame damper
The rear frame damper features air suspension, a
compression damper and a rebound damper.
.
Figure 28: Monarch RL as an example
1 Threshold lever
2 Rebound damper adjuster
3 Air valve
4O-ring
5Scale
1
2
3
4
5
