MY22Z0a - 12_1.0_25.07.2022
139
Operation
6.5.14.1 Adjusting the Suntour rear frame damper
Only applies to pedelecs with this equipment
Every rear frame damper has a specific delivery
air pressure ex works. These levels are starting
points. These settings can be changed based on
riding skills, trail conditions, frame design and
personal preferences.
After setting up the rear wheel damper, check the
sag to ensure the recommended sag settings are
used.
The fork sag is adjusted.
When adjusting the sag, ensure that the
compression and rebound adjuster is in an open
position, i.e. the lockout lever is in the OPEN
position.
1 Remove the valve cap from the air valve.
2 Attach a fork/damper pump to the valve.
3 Pump the damper to the required pressure.
Never exceed the recommended maximum air
pressure.
4 Detach high-pressure damper pump.
5 Measure the distance between the air chamber
seal and the end of the rear frame damper.
This distance is the total rear frame damper
deflection.
6 Use the O-ring or a cable tie on the damper
body to gauge the sag correctly.
7 Put on your normal cycling clothing, including
baggage.
8 Sit on the pedelec in your usual riding position
and support yourself against an object, such as
a wall or tree.
9 Push the O-ring or cable tie downwards
against the air chamber seal.
10 Get off the pedelec without the suspension fork
deflecting.
11 Measure the distance between the air chamber
seal and the O-ring. This measurement is the
sag. The recommended value is between 25%
(hard) and 30% (soft) of the total rear frame
damper deflection.
12 Increase or reduce the air pressure until you
have reached the desired sag.
If the sag is correct, fasten the valve cap onto
the valve.
Recommended air pressure (psi)
Body weight Triair EDGE-TT EDGE RAIDON
Main body Air reservoir Main body Main body Main body
Air pressure
Factory reset
180 200 110 110 110
Maximum air
pressure
300 240 300 300 300
Table 45: Suntour filling pressure table for the rear frame damper
Notice
If the air pressure in the rear frame damper is
exceeded or undershot, the damper can be
permanently damaged.
Do not exceed the maximum air pressure of
300 psi (20 bar).
Deflection Sag
30–45 15–25
50–75 20–25
Table 46: Recommended sag for the rear frame damper
