Description
3.3.10.3 Charger
Each pedelec is supplied with a charger. The
following BOSCH charger may be used:
• the 4 A Charger BPC3400.
Observe the operating instructions in the
Section 11.4 Documents.
3.3.10.4 Lighting
When the riding light is activated, the front light
and rear light are switched on together at the
same time.
3.3.10.5 Integrated battery
The following battery can be built into the pedelec:
Figure 41: Overview of integrated battery
Figure 42: Detail of PowerTube 750
1 Securing hook
2 Battery lock
3 Battery key
4 Retainer guard
5 On-Off button (battery)
6 Battery level indicator (battery)
7 Socket for charger plug
8 Battery housing
PowerTube 750
12
3
1
4
5
6
7
8
