Description
3.3 Components
3.3.1 Overview
Figure 3: Pedelec viewed from right, Bull Cross Rider EVO 2 used as example
1 Front wheel
2 Front wheel hub
3 Fork
4 Front wheel mudguard
5 Front light
6 Steering headset
7 Handlebars
8Stem
9Frame
10 Seat post
11 Saddle
12 Pannier rack
13 Reflector
14 Rear light
15 Rear wheel mudguard
16 Rear wheel brake
17 Kickstand
18 Rear wheel
19 Gear shift and rear wheel
hub
20 Chain
21 Frame number
22 Chain guard
23 Motor
23 Motor cover
24 Pedal
25 Rechargeable battery
22 Nameplate
26 Front wheel brake
1
2
3
14
4
5
6
7
891011
16
12
13
18
15
19 20
21
22
23 24
17
25
26
