Bosch ZEMO SU-E FS 12 - Handlebars; Fork

MY22Z0a - 12_1.0_25.07.2022
36
Description
3.3.3.5 Handlebars
The pedelec is steered using the handlebars. The
handlebars are used to support the upper body
and is the mount for most controls and displays
(see Section 3.4.1).
Figure 15: Handlebar dimensions
The main dimensions of handlebars are:
1 Rise (height)
2Width
3 Backsweep
3.3.3.6 Fork
The stem and handlebars are attached to the top
end of the fork steerer. The axle is fastened to the
fork ends. The wheel is fastened to the axle.
Figure 16: Overview of fork
1 Fork steerer
2 Side reflectors (optional)
3 Fork end
4 Fork leg
1
2
3
1
2
3
4
