Description
3.5 Technical data
3.5.1 Pedelec
3.5.2 Emissions
The safety requirements as per Electromagnetic
Compatibility Directive 2014/30/EU have been
met. The pedelec and the charger can be used in
residential areas without restriction.
3.5.3 Bicycle lighting
3.5.4 Display mount
3.5.5 LED Remote on-board computer
*Not included in the standard scope of delivery
3.5.6 BOSCH Performance Line CX motor
Power output/system 250 W (0.25 kW)
Shut-off speed 25 km/h
Charging temperature 0°C…+45°C
Operating temperature -5 °C…+40 °C
Storage temperature +10 °C…+50 °C
Table 16: Pedelec technical data
A-weighted emission sound
pressure level
<70dB(A)
Total vibration level for the hands
and arms
<2.5m/s²
Highest effective value of
weighted acceleration for the
entire body
<0.5m/s²
Table 17: Emissions from the pedelec*
Voltage about 12 V
Maximum output
Front light 17.4 W
Rear light 0.6 W
Table 18: Bicycle lighting
Output voltage 4.75… 5.4 V
Output current, max. 1.5 A
Operating temperature -5… +40 °C
Storage temperature +10… +40 °C
Protection class IP54
Table 19: Technical data for BOSCH Display Mount
BDS3210 | BDS3250 | BDS3620 | BDS3630
Internal lithium ion battery 3.7 V, 75 mAh
Charging temperature 0°C…+45°C
Operating temperature -5 °C…+40 °C
Storage temperature +10 °C…+50 °C
Protection class IP54
Dimensions 74 × 53 × 35
Weight 0.03 kg
Diagnosis interface
Interface USB type C®
USB charging cable* USB type C®
Max. charging current for USB port 600 mA
USB port charge voltage 5V
BLUETOOTH low energy®
Frequency 2400…2480 MHz
Transmitting capacity 1 mW
Table 20: Technical data for BOSCH LED Remote on-
board computer, BRC3600
Maximum continuous power rating 250 W
Max. torque 85 Nm
Nominal voltage 36 V DC
Protection class IP54
Weight about 3 kg
Operating temperature -5… +40 °C
Storage temperature -10… +40 °C
Table 21: Technical data for BOSCH Performance Line CX
motor, BDU3740, BDU3741
